Allen & Heath ZEDi-10FX

The Allen & Heath ZEDi-10FX is a hybrid compact mixer and USB audio interface that brings Allen & Heath’s signature sound to small venues, rehearsal rooms, and home studios. Its ten channels include four mic/line inputs with preamps derived from the GS-R24 studio console, two Hi-Z instrument inputs, and two stereo inputs, plus built-in effects and a 4-in/4-out 24-bit/96 kHz USB interface for recording.

Highlights

• 4 mic/line inputs with separate XLR and TRS jacks and 48 V phantom power
• Preamps derived from the Allen & Heath GS-R24 for low noise and wide headroom
• 2 Hi-Z guitar inputs, eliminating the need for DI boxes
• 3-band EQ and high-pass filters on channels 1-4
• Built-in FX with reverb, delay, chorus, and tap tempo
• 4×4 USB audio interface, 24-bit/96 kHz; Cubase LE and Cubasis LE included

Allen & Heath ZEDi-10FX: Live Mixing and Recording in One

The ZEDi-10FX is equally at home mixing a small gig and tracking a rehearsal or demo. Its analog channels deliver Allen & Heath’s warm, musical sound, while the USB interface sends four channels to your computer and returns four for playback. A USB routing switch lets you choose how channels are sent to your DAW, so you can record individual mics or the main mix.

Preamps, EQ, and Effects

The preamps are derived from the Allen & Heath GS-R24 studio console for warmth, low noise, and plenty of headroom. Channels 1-4 have 3-band EQ and high-pass filters, and two channels switch to high impedance so guitars and basses can plug in directly. The onboard effects engine adds reverb, delay, and chorus with tap tempo for polished live sound.

Setting Up the ZEDi-10FX

Connect microphones to the XLR inputs, enabling phantom power for condensers, and plug guitars into the Hi-Z inputs. Connect keyboards or playback devices to the stereo inputs, and the XLR main outputs to your PA. For recording, connect USB to your computer, choose the USB routing, and record in Cubase LE or your preferred DAW.

What to Pair With the ZEDi-10FX

Pair the ZEDi-10FX with powered speakers, vocal and instrument microphones, closed-back headphones, studio monitors, and a laptop for recording.

Why a Hybrid Mixer?

A hybrid mixer combines an analog mixer and an audio interface in one box, so you don’t need separate gear for gigs and recording. Mix a live show and capture it at the same time, or use the ZEDi-10FX as the hub of a home studio, with hands-on controls that are faster than adjusting levels on a screen.

Small-Venue Workhorse

With ten channels, the ZEDi-10FX handles singer-songwriter gigs, acoustic duos, small bands, presentations, and houses of worship. Its internal power supply, 60 mm main fader, and LED metering make it simple and reliable for regular use.

Allen & Heath ZEDi-10FX FAQ

Can it record to a computer? Yes. It’s a 4×4 USB interface at up to 24-bit/96 kHz, with Cubase LE included.

Do I need a DI box for guitar? No. Two channels have switchable high-impedance inputs.

Allen & Heath ZEDi-10FX Specifications at a Glance

• Channels: 10 (4 mic/line, 2 stereo; 2 Hi-Z switchable)
• Preamps: GS-R24-derived, 48 V phantom
• EQ: 3-band with high-pass filter (ch 1-4)
• FX: reverb, delay, chorus, tap tempo
• USB: 4-in/4-out, 24-bit/96 kHz
• Outputs: 2 XLR main, RCA monitor, headphone
• Software: Cubase LE, Cubasis LE

Who Buys the Allen & Heath ZEDi-10FX

• Singer-songwriters and small bands
• Home and project studios
• Churches and schools
• Small venues and coffee shops

Why Buy the Allen & Heath ZEDi-10FX From Metro Sound & Lighting

Metro Sound & Lighting isn’t a catalog-only retailer. We design, install, and service sound systems in-house, so our team can help you choose the right mixer and support your system after the sale. We offer B2B and integrator pricing for churches, schools, and venues.

Browse more options in our Analog Mixers category, or see the full specifications on the official Allen & Heath ZEDi Compact product page.
