ADJ WMX1 MK2

The ADJ WMX1 MK2, powered by Wolfmix, is a standalone DMX lighting controller built for performers who want to create high-impact light shows on the fly without a computer. A 4.3-inch color touchscreen, 37 backlit silicone buttons, rotary encoders, FX modules, and eight fixture groups make programming fast and intuitive, while MK2 upgrades add larger encoder caps, MIDI triggering, and a USB-A socket.

Highlights

• Standalone controller; no computer needed
• 4.3-inch color touchscreen and 37 backlit silicone buttons
• 2 DMX universes standard, expandable to 4 via the WTOOLS app
• Color, Move, and Beam FX modules with 8 effect types each
• 8 fixture groups and 100 namable presets
• MIDI triggering and USB-A for MIDI controllers or memory sticks

ADJ WMX1 MK2: Light Shows Without a Laptop

The WMX1 MK2 is designed around fixture groups and FX modules rather than complex cue programming, so DJs and performers can build looks quickly and run shows live. Touch the XY grid to position moving heads, pick colors on the RGBW color picker, and fire flash buttons for strobe, blinder, and smoke.

Powerful FX Engine

Color, Move, and Beam FX modules each offer eight effect types, with control over speed, phase, order, size, fade, fan, and flick. An 8-step real-time sequencer creates custom beam and movement effects, and global FX speed and freeze give instant control.

Setting Up the WMX1 MK2

Connect the controller to your fixtures with DMX cables, add fixtures from the onboard library or build your own with Fixture Builder, and assign DMX addresses and groups. Create palettes and presets, then perform live using the touchscreen, buttons, and encoders.

What to Pair With the WMX1 MK2

Pair the WMX1 MK2 with DMX cables, moving heads, LED bars and PARs, a haze machine, and a padded controller case.

Music Sync

FX can pulse to music from a microphone or line input, or sync BPM with Ableton Link, OS2L, or tap tempo, keeping your light show locked to the beat.

Large Fixture Library

Thousands of fixture profiles are available, with thousands stored on the controller, and Fixture Builder lets you create profiles for anything not in the library. WTOOLS software backs up projects and fixtures and enables 3D offline visualization.

Reliable Performance

The controller starts in under two seconds, auto-recovers the active project, and can be locked with a password to prevent accidental changes during a show.

ADJ WMX1 MK2 FAQ

Does it need a computer? No. It’s a standalone controller.

How many DMX universes does it have? Two standard, expandable to four via add-ons in the WTOOLS app.

ADJ WMX1 MK2 Specifications at a Glance

• Display: 4.3-inch color touchscreen
• Controls: 37 backlit silicone buttons, rotary encoders
• Universes: 2 standard, up to 4
• Fixtures: up to 680 fixtures and beams, 50 fixture types
• Groups/presets: 8 groups, 100 presets
• Sync: mic/line pulse, Ableton Link, OS2L, tap
• Extras: MIDI triggering, USB-A socket

Who Buys the ADJ WMX1 MK2

• Mobile DJs
• Bands with their own lighting
• Bars and clubs
• Churches and small venues

Why Buy the ADJ WMX1 MK2 From Metro Sound & Lighting

Metro Sound & Lighting isn’t a catalog-only retailer. We sell, install, and service lighting systems in-house, so our team can help you program your rig and support it after the sale. We offer B2B and integrator pricing for venues and production companies.

Browse more options in our DMX Controllers category, or see the full specifications on the official ADJ WMX1 MK2 product page.
