Mackie 2404VLZ4

The Mackie 2404VLZ4 is a 24-channel, 4-bus analog mixer with built-in effects, compression, and USB recording, made for live sound, worship, schools, and studios. Twenty boutique-quality Onyx mic preamps, six aux sends, four subgroups with dedicated compressors, and dual 32-bit RMFX+ effects processors deliver serious mixing power, while Mackie’s built-like-a-tank steel chassis ensures years of dependable use.

Highlights

• 24 channels with 20 Onyx mic preamps and phantom power
• 4 subgroups and 6 aux sends
• 8 one-knob compressors: on 4 channels and all 4 subgroups
• Dual RMFX+ processors with 24 reverbs, choruses, and delays
• 4×2 24-bit USB recording and playback
• 3-band EQ with sweepable mid and 100 Hz low-cut

Mackie 2404VLZ4: A Full-Featured Analog Console

The 2404VLZ4 brings big-console routing to a compact frame. Four subgroups let you group drums, vocals, or a choir for easy control, while six aux sends handle monitor mixes and effects. Main stereo and mono outputs, group outputs with inserts, and control room outputs give you flexible connections for any system.

Onyx Preamps

Mackie’s Onyx preamps offer a 60 dB gain range, 128.5 dB dynamic range, +22 dBu line handling, and very low distortion for clean, detailed sound from any microphone. Improved RF rejection makes the 2404VLZ4 suitable for broadcast use.

Setting Up the 2404VLZ4

Connect microphones and instruments to the inputs, and connect the main XLR outputs to your PA and aux sends to monitors. Set gain with the PFL solo and meters, assign channels to subgroups for easy control, and apply one-knob compression to vocals and groups. Connect USB to record four tracks or a stereo mix.

What to Pair With the 2404VLZ4

Pair the 2404VLZ4 with powered speakers and stage monitors, vocal and instrument microphones, a snake or stage box, a mixer case, and a computer for recording.

Built-In Compression and Effects

One-knob compressors on the last four mic channels and all four subgroups keep vocals, snare, guitars, and groups under control. Dual 32-bit RMFX+ processors provide 24 gig-ready reverbs, choruses, and tap delay without outboard gear.

USB Recording and Playback

The 4×2 USB interface streams subgroups or the main mix to your computer and returns a stereo signal for playback. You can even use plug-ins live through aux sends 5 and 6.

Built Like a Tank

A rugged steel chassis with powder-coat finish, sealed rotary controls that resist dust, and high-contrast controls make the 2404VLZ4 a reliable workhorse for daily use.

Why Choose Analog?

An analog console puts every control on the surface, with no menus or layers, so volunteers and guest engineers can mix confidently right away. The 2404VLZ4 combines that immediacy with modern conveniences like built-in compression, effects, and USB recording.

Mixing Tips

Set gain first using PFL and the meters, then use the low-cut filter on vocal and instrument mics to clean up rumble. Group similar sources to subgroups so you can ride an entire section with one fader, and apply subgroup compression to glue drums or choirs together.

Mackie 2404VLZ4 FAQ

Does it have effects? Yes. Dual RMFX+ processors provide 24 reverbs, choruses, and delays.

Can I record with it? Yes. The USB interface records up to four channels.

Mackie 2404VLZ4 Specifications at a Glance

• Channels: 24 (20 mono mic/line, 2 stereo)
• Mic preamps: 20 Onyx with phantom
• Buses: 4 subgroups, 6 aux sends
• Compressors: 8 one-knob
• Effects: dual RMFX+, 24 presets
• USB: 4×2, 24-bit
• Outputs: XLR stereo and mono mains, groups, control room
• Weight: 31 lbs

Who Buys the Mackie 2404VLZ4

• Churches and houses of worship
• Bands and live sound engineers
• Schools and theaters
• Studios and AV companies
